Precision Door Jam Wire Loom BDP 003-2

Name: Precision Door Jam Wire Loom BDP 003-2
Brand: Precision Replacement Parts
SKU: 5066395
Price: 52.99 CAD
Availability: OnlineOnly

$52.99 pr

NEWARRIVING SOONEstimated Ship Date 01/01/2026 (If Ordered Today)

Model: 5066395

0 reviewsWrite a Review Add to Wish List

Select a Vehicle or refer to the Vehicle Fitment Tab below to verify that this part fits your vehicle.

CALL US
855.444.6872

Description Vehicle Fitment Specifications Reviews (0) Product Q&A Related Products

The Precision Door Jam Wire Loom BDP 003-2 is a preformed door-jamb wiring loom designed to protect and organize the electrical harness where the vehicle body meets the door. It prevents chafing, moisture intrusion, and pinching of wires that can cause shorts or intermittent electrical faults. Engineered as a direct-fit replacement for worn or damaged looms, this part restores factory routing and clip locations to maintain reliable door functions such as power windows, locks, mirrors, and speakers. Durable materials and OE-style clips make it a long-lasting, easy-to-install solution for maintenance and restoration projects.

Features:

Direct-fit replacement designed to restore factory door-harness routing and clip positions.
Constructed from flexible, abrasion-resistant thermoplastic with integrated grommet and boot sections.
Preformed shape and OE-style clips secure wiring, reducing vibration and preventing chafe.
Seals and protects connectors from moisture and contaminants to improve electrical reliability.
Ideal for restoring aged, cracked, or torn door-jam looms during vehicle maintenance or restorations.

Installation / Application:

Difficulty: 2/5
Estimated time: 30–60 minutes

Suggested Tools:

10mm socket or appropriate wrench
Flathead and Phillips screwdrivers
Trim panel removal tool or plastic pry tool
Needle-nose pliers
Electrical tape or heat-shrink tubing
Zip ties

Instructions:

Park on a level surface, set the parking brake and disconnect the negative battery terminal to avoid accidental shorting.
Open the door and remove any trim or weatherstrip that blocks access to the rubber boot between the door and body. Use a trim tool to avoid damage.
Carefully peel back or remove the rubber boot/grommet to expose the harness and loom inside the door-jam area.
Unclip the old loom from the body and door hinge area. If necessary, remove fasteners or push clips using a trim tool or pliers.
Disconnect any door-side connectors that are in-line with the loom (note connector positions or take photos for reference).
Remove the old loom completely and compare with the new BDP 003-2 to confirm clip and grommet locations match.
Route the new loom into the same path, feed wiring through the grommet/boot, and seat the boot into the door and body openings.
Reconnect electrical connectors and secure the harness with the OE-style clips or supplied fasteners; use zip ties if additional support is needed.
Reinstall any removed trim, weatherstrip, and door panel, ensuring clips and screws are tightened to factory specifications.
Reconnect the negative battery terminal and test door electrical functions (windows, locks, mirrors, speakers) to confirm proper installation.

About Precision Replacement Parts

Since 1986 Precision Replacement Parts has been a trusted name in the Automotive Glass Industry.

Our knowledge and experience in manufacturing millions of extruded and molded EPDM Rubber, PVC and HDPE based plastics, and various stamped and extruded metal products for the classic and late model industries has allowed Precision to expand our services into multiple product markets.

Along with our own USA based production facility, Precision also partners with 25 different manufactures worldwide with a reputation as a global leader supplying OEM and replacement products to a number of different industries. Our partnerships along with our own in-house manufacturing and fabrication capability gives Precision a unique position in helping to meet the expanding needs of customers everywhere, providing them with a sustained competitive advantage.

Vehicle Fitment:

The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.

Make	Model	Years
Chevrolet	Blazer	1973 - 1991
Chevrolet	C10 Pickup	1973 - 1974
Chevrolet	C10 Suburban	1973 - 1986
Chevrolet	C10	1975 - 1986
Chevrolet	C20 Pickup	1973 - 1974
Chevrolet	C20 Suburban	1974 - 1986
Chevrolet	C20	1975 - 1986
Chevrolet	C30 Pickup	1973 - 1974
Chevrolet	C30	1975 - 1986
Chevrolet	C50	1973 - 1990
Chevrolet	K10 Pickup	1973 - 1974
Chevrolet	K10 Suburban	1974 - 1986
Chevrolet	K10	1975 - 1986
Chevrolet	K20 Pickup	1973 - 1974
Chevrolet	K20 Suburban	1973 - 1986
Chevrolet	K20	1975 - 1986
Chevrolet	K30 Pickup	1973 - 1974
Chevrolet	K30	1977 - 1986
Chevrolet	K5 Blazer	1975 - 1986
Chevrolet	R10 Suburban	1987 - 1988
Chevrolet	R10	1987
Chevrolet	R20 Suburban	1987 - 1988
Chevrolet	R20	1987 - 1988
Chevrolet	R2500	1989
Chevrolet	R30	1987 - 1988
Chevrolet	R3500	1989 - 1991
Chevrolet	V10 Suburban	1987 - 1988
Chevrolet	V10	1987
Chevrolet	V20 Suburban	1987 - 1988
Chevrolet	V20	1987
Chevrolet	V30	1987 - 1988
Chevrolet	V3500	1989 - 1991
GMC	C15 Suburban	1975 - 1978
GMC	C15/C1500 Pickup	1973 - 1974
GMC	C15/C1500 Suburban	1973 - 1974
GMC	C1500 Suburban	1979 - 1986
GMC	C1500	1979 - 1986
GMC	C15	1975 - 1978
GMC	C25 Suburban	1975 - 1978
GMC	C25/C2500 Pickup	1973 - 1974
GMC	C25/C2500 Suburban	1973 - 1974
GMC	C2500 Suburban	1979 - 1986
GMC	C2500	1979 - 1986
GMC	C25	1975 - 1978
GMC	C35/C3500 Pickup	1973 - 1974
GMC	C3500	1979 - 1986
GMC	C35	1975 - 1978
GMC	C5000	1979 - 1990
GMC	Jimmy	1976 - 1991
GMC	K15 Suburban	1975 - 1978
GMC	K15/K1500 Suburban	1973 - 1974
GMC	K1500 Suburban	1979 - 1986
GMC	K1500	1979 - 1986
GMC	K15	1975 - 1978
GMC	K25 Suburban	1975 - 1978
GMC	K25/K2500 Pickup	1973 - 1974
GMC	K25/K2500 Suburban	1973 - 1974
GMC	K2500 Suburban	1979 - 1986
GMC	K2500	1979 - 1986
GMC	K25	1975 - 1978
GMC	K35/K3500 Pickup	1973 - 1974
GMC	K3500	1979 - 1986
GMC	K35	1977 - 1978
GMC	R1500 Suburban	1987 - 1991
GMC	R1500	1987
GMC	R2500 Suburban	1987 - 1991
GMC	R2500	1987 - 1989
GMC	R3500	1987 - 1991
GMC	V1500 Suburban	1987 - 1991
GMC	V1500	1987
GMC	V2500 Suburban	1987 - 1991
GMC	V2500	1987
GMC	V3500	1987 - 1991

Specifications:

Part Type	Vent Window Weatherstrip
Proposition 65	www.P65Warnings.ca.gov
Warranty	Lifetime on Defects TX
